NTN NU1008 Bearing Specification
![Bearing NU1008](/wp-content/uploads/2023/09/nu-ntn.png)
Bearing number : NU1008
Size (mm) : 40x68x15
Brand : NTN
Bore Diameter (mm) : 40
Outer Diameter (mm) : 68
Width (mm) : 15
Bearing dimensions and specification in YHY catalogue:
d – 40 mm
Fw – 47 mm
D – 68 mm
B – 15 mm
C – 15 mm
r min. – 1 mm
r1 min. – 0,6 mm
Weight – 0,22 Kg
Basic dynamic load rating (C) – 27,3 kN
Basic static load rating (C0) – 29 kN
(Grease) Lubrication Speed – 11 000 r/min
(Oil) Lubrication Speed – 13 000 r/min
Tags : YHY , 40x68x15
NTN NU1008 Bearing Description
We supply various of NTN NU1008 bearings. bearings is purity material and high precision , the varieties of NTN bearings is up to thousands of species .NTN NU1008 bearings is known as ” the food of machinery industry” and widely used in different environment and mechanical.The purpose of NTN NU1008 bearings is the operation and control. In order to ensure the smooth operation and normally rotation,NTN NU1008 bearings inquire deeply into the running of the machine and friction phenomenon .NTN NU1008 bearings is widely used in automobile, motor, gear, injection molding machines, machine tools, mining machinery, engineering machinery, motorcycles, office equipment, paper making machinery, pumps and compressors, wind power generator and so on.The shipment of NTN NU1008 bearings will be arranged timely for we have a large stock of NTN NU1008 bearings in HongKong.
